Rof Electro-optic modulator EDFA Optical Amplifier Ytterbium-Doped Fiber Amplifier YDFA Amplifier

Tsanangudzo Pfupi:

An optical amplifier mudziyo unogamuchira mwenje wekuisa chiratidzo uye unoburitsa chiratidzo chinobuda chine simba repamusoro rekuona.Kazhinji, zvinopinza uye zvinobuda ma laser matanda (kazhinji kashoma mamwe marudzi emwenje mwenje), angave achipararira semaGaussian matanda munzvimbo yemahara kana mufiber.Kukwidziridzwa kunoitika mune inodaidzwa kuti gain medium, iyo inofanirwa ku "pump" (kureva, kupihwa simba) kubva kune yekunze sosi.Mazhinji optical amplifiers anogona kunge ari optically kana emagetsi kupomba.
Mhando dzakasiyana dzeamplifiers dzinosiyana zvakanyanya semuenzaniso maererano nekuzara kwezvivakwa.Semuenzaniso, isingawanzo-yepasi-doped laser kuwana midhiya inogona kuchengetedza huwandu hwakakura hwesimba, nepo optical parametric amplifiers inopa kukwidziridzwa chete sekunge pombi yepombi iripo.Semumwe muenzaniso, semiconductor optical amplifiers inochengetedza simba shoma pane fiber amplifiers, uye izvi zvine zvakakosha kune optical fiber communications.


Product Detail

Rofea Optoelectronics inopa Optical uye photonics Electro-optic modulators zvigadzirwa

Product Tags

Feature

* Ruzha rwakaderera
* ACC, AGC, APC Sarudzo
* SM uye PM faibha Sarudzo
* Kuvhara otomatiki kudzivirira pombi
* Remote control
* Desktop, module package ndeye sarudzo

20dbm EDFA Module

Application

• Amplifier inogona kuwedzera (avhareji) simba relaser kubuda kusvika kumazinga epamusoro (→ master oscillator simba amplifier = MOPA).
•Inokwanisa kuburitsa masimba epamusoro zvakanyanya, kunyanya muma ultrashort pulses, kana simba rakachengetwa rikatorwa mukati menguva pfupi.
•Inokwanisa kukwidziridza masaini asina kusimba pamberi pefotodetection, uye nokudaro kuderedza ruzha rwekuona, kunze kwekunge yakawedzera amplifier ruzha rwakakura.
•Muhurefu hwefiber-optic links for optical fiber communications, simba remaziso rinofanira kusimudzwa pakati pezvikamu zvakareba zvefiber ruzivo rusati rwarasika muruzha.

Parameters

Parameter

Unit

Minimum

Typical

Maximum

Kushanda wavelength range

nm

1050

1100

Input signal power range

dBm

-3

0

10

Saturated kubuda optical simba *

dBm

30

33

Noise index @ Input 0 dBm

dB

5.0

6.0

Input Optical isolation

dB

30

Output optical isolation

dB

30

Dzorera kurasikirwa

dB

40

Polarization zvinoenderana kuwana

dB

0.3

0.5

Input pump leakage

dBm

-30

Kubuda kwepombi yekubuda

dBm

-40

Operating voltage desktop

V( AC )

80

240

Fiber type

HI1060

Output interface

FC/APC

Kukurukurirana interface

RS232

Saizi yepakeji module

mm

90×70×18

desktop

320×220×90

Kuraira ruzivo

ROF YDFA XX XX X XX
  Ytterbium-Doped Fiber Amplifier HP--High goho mhando Output power:

20---20dBm

23---23dBm

30---30dBm

33---33dBm

Saizi yepakeji

D---desktop

M---module

Optical fiber connector:

FA---FC/APC




  • Zvakapfuura:
  • Zvinotevera:

  • Rofea Optoelectronics inopa mutsara wechigadzirwa chekutengesa Electro-optic modulators, Phase modulators, Intensity modulator, Photodetectors, Laser light sources, DFB lasers,Optical amplifiers, EDFA, SLD laser, QPSK modulation, Pulse laser, Chiedza detector, Balanced driver photodetector, Laser. , Fiber optic amplifier, Optical power meter, Broadband laser, Tunable laser, Optical detector, Laser diode driver, Fiber amplifier.Isu tinopawo akawanda ma modulator ekugadzirisa, akadai se 1 * 4 array phase modulators, Ultra-low Vpi, uye ekupedzisira-yepamusoro yekutsakatika ratio modulators, inonyanya kushandiswa mumayunivhesiti nemasangano.
    Tariro kuti zvigadzirwa zvedu zvichabatsira iwe nekutsvaga kwako.
